Mining & quarrying
Crusher wear parts
Jaw plates and cheek plates, cone mantles and concaves, blow bars, hammers, impact and breaker bars, grizzly bars, feeder pans.
Grades — ASTM A128 Gr B-2 / B-3 / B-4, IS 276 Gr I–III
Home / Products
Products
High manganese and alloy steel castings, made to customer drawings and to national and international specifications.
Made to order
We cast what your equipment needs, not what is on a shelf.
Pattern, grade, hardness range and machining allowance are set against your drawing. Where you are not sure of the grade, tell us the duty and the failure mode you are seeing and we will recommend one.
Cement & minerals
Mill and kiln components
Ball and rod mill liners, diaphragm and grate plates, lifter bars, kiln and cooler grate plates, chute and hopper liners, wear plates.
Grades — Mn steel, low-alloy steel, abrasion-resistant alloy
Railways
Track and rolling stock
Crossings and frogs, check rail assemblies, sleeper and bogie components, coupler and draft gear castings to railway specifications.
Grades — Austenitic Mn steel, cast carbon and low-alloy steel
Earthmoving & dredging
Ground engaging tools
Bucket teeth and adapters, dipper and dredge teeth, lip shrouds, side cutters, ripper points, wear runners, dragline components.
Grades — ASTM A148, AISI 4140-type low-alloy steel
Steel & heat treatment
Heat and corrosion resistant
Furnace fixtures, trays, grids, skid rails, radiant tubes, quench baskets and sinter plant components for sustained high-temperature duty.
Grades — ASTM A297 HH / HK / HP, stainless CF8 / CF8M
General engineering
Structural castings
Pump and valve bodies, gear and sprocket blanks, coupling halves, housings, brackets and heavy structural castings.
Grades — ASTM A216 WCB, A217, IS 1030, EN equivalents
Metallurgy
Grades we pour.
Where a customer specification differs from a published standard, the customer specification governs.
| Family | Representative standards | Behaviour | Typical use |
|---|---|---|---|
| Austenitic manganese | ASTM A128 Gr A, B-1 to B-4, C, D, E-1, E-2; IS 276 Gr I, II, III | Work hardens under impact, high toughness | Crusher jaws, mantles, hammers, rail crossings |
| Low-alloy steel | ASTM A148, A487; AISI 4140 / 4340 type | High strength, through-hardening response | GET, dredge teeth, gear blanks, heavy structures |
| Carbon steel | ASTM A216 WCA / WCB / WCC; IS 1030 Gr 280-520 | Weldable, general purpose | Housings, brackets, valve and pump bodies |
| Heat resistant | ASTM A297 HH, HK, HP; A351 HT / HU | Creep and oxidation resistance to about 1150 °C | Furnace trays, grids, radiant tubes, skid rails |
| Stainless steel | ASTM A351 CF8, CF8M, CA15, CA6NM | Corrosion and cavitation resistance | Pump casings, impellers, chemical duty |
| Abrasion resistant | ASTM A532 equivalents and customer grades | Very high hardness, low-impact abrasion | Mill liners, chute liners, wear plates |
Availability depends on section thickness, quantity and heat treatment route. Confirm the exact specification with our engineering team at enquiry stage.
Envelope
What fits through the plant.
These are the practical limits set by our melting, moulding, heat treatment and machining equipment. Parts outside them can often be split, cast and assembled — worth asking.
- Piece weight
- 5 kg to approximately 10,000 kg poured weight
- Pouring
- Bottom-pour ladles 5, 10 and 15 MT; tilting ladles 300 kg, 500 kg, 2 MT
- Moulding
- Two-part no-bake finotech resin sand, PLC-controlled mixing
- Heat treatment
- 5 MT and 15 MT batch solution annealing with water quench
- Machining
- Vertical boring to 1200 mm spindle diameter, milling, planing, shaping, drilling
- Surface
- Shot blasting on a 1.5 m table, grinding, pneumatic chipping
- Lead time
- 6–10 weeks on repeat patterns; 12–16 weeks where new pattern work is needed
Sectors
Discuss a part
Where the castings end up.
Mining and mineral processing
Cement and limeSteel and metallurgy
Thermal power
Quarrying and aggregates
Earthmoving and dredging
